- 5 -
Copyright ©2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3. Wiring Diagrams
Indoor Unit
CN-MAINCN-TACT
CN-LIMIT CN-PLASMA
CN-DISPLAY
Sub PCB
CN-HVB
CN-DISP1
CN-TH1
CN-TH2
CN-REMO
CN-OPTION
CN-COM
CN-L1
CN-SUB
CN-L/R
CN-U/D
CN-12V
CN-DISP3
CN-IN/N1
CN-TH3
Main PCB
