MULTI V Wall-Mounted Indoor Unit Engineering Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
&RROLQJ&DSDFLW\7DEOHV
Table 8: ARNU093SFA4, ARNU123SFA4 Cooling Capacity Table.
ARNU093SFA4, ARNU123SFA4
TC: Total Capacity (MBh); SHC: Sensible Heat Capacity (MBh).
Model No. /
Capacity Index
Outdoor
Air Temp.
(°F DB)
Indoor Air Temperature (°F DB / WB)
68 / 57 73 / 61 79 / 64 80 / 67 85 / 70 88 / 73 91 / 76
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh
ARNU093SFA4 /
9.6
23 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
25 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
30 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
35 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
40 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
45 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
50 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
55 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.4 7.3
60 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.3 7.2
65 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 12.1 7.1
70 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 11.9 7.0
75 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.4 7.3 11.6 6.9
80 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.8 7.4 11.1 7.2 11.3 6.8
85 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.6 7.3 10.8 6.9 11.0 6.5
90 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.5 7.2 10.6 6.8 10.8 6.5
95 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.3 7.1 10.5 6.8 10.6 6.4
100 6.3 5.2 7.7 6.0 8.6 6.4 9.6 6.9 10.1 7.0 10.3 6.7 10.5 6.4
105 6.3 5.2 7.3 5.7 8.2 6.2 9.2 6.5 9.6 6.5 9.9 6.5 10.2 6.2
110 6.2 5.1 6.9 5.4 7.7 5.7 8.6 6.2 9.0 6.2 9.4 6.2 9.8 6.0
ARNU123SFA4 /
12.3
23 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.9 9.4
25 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.9 9.4
30 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.9 9.4
35 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.9 9.4
40 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8
9.5 14.7 9.4 15.9 9.4
45 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.9 9.4
50 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.9 9.4
55 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.9 9.4
60 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.7 9.4
65 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.5 9.2
70 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 15.3 9.1
75 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.7 9.4 14.9 8.9
80 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.8 9.5 14.2 9.4 14.5 8.8
85 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.6 9.4 13.8 9.0 14.0 8.5
90 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.4 9.3 13.5 8.8 13.8 8.4
95 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 13.2 9.2 13.4 8.8 13.6 8.3
100 8.1 6.8 9.8 7.8 11.1 8.3 12.3 8.9 12.9 9.1 13.2 8.7 13.4 8.2
105 8.1 6.8 9.3 7.4 10.6 8.0 11.8 8.5 12.3 8.5 12.7 8.4 13.0 8.0
110 7.9 6.6 8.9 7.0 9.8 7.4 11.1 8.0 11.6 8.0 12.0 8.0 12.6 7.8
