HIGH STATIC | 33
Ducted High Static
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Table 21: M3 Unit External Static Pressure and Air Flow Table.
1. All static pressure air flow rates are listed in CFM.
2. The tables above show the correlation between air flow rates and external static pressure.
3. The tables above show the available external static pressure range.
If the external static pressure of the installed indoor unit is less than the lowest value (as mentioned in the table), the indoor unit components can fail.
External Static Pressure and Air Flow Tables
DUCTED HIGH STATIC
M2, M3 Units
Table 22: ARNU283~423M2A4 External Static Pressure and Air Flow Table.
ARNU283~423M2A4 External Static Pressure and Air Flow Table.
M2 Unit External Static Pressure and Air Flow Table.
Set value
Static Pressure (in wg)
0.16 0.24 0.31 0.39 0.47 0.55 0.63 0.71
Air Flow Rate[CFM]
90 812
95 914 676
100 1010 823
105 1110 931 691
110 1208 1056 854
115 1292 1153 1016 765
120 1383 1260 1121 926 692
125 1473 1358 1227 1087 857
130 1554 1456 1332 1203 1023 787
135 1545 1437 1318 1150 971 723
140 1534 1426 1313 1151 909 701
145 1533 1468 1320 1084 868
150 1532 1493 1249 1036
155 1543 1324 1155
ARNU283~543M3A4 External Static Pressure and Air Flow Table.
M3 Unit External Static Pressure and Air Flow Table.
Set value
Static Pressure (in wg)
0.16 0.24 0.31 0.39 0.47 0.55 0.63 0.71 0.79
Air Flow Rate [CFM]
70 891
75 1074 756
80 1235 959 654
85 1404 1250 869
90 1562 1416 1111 800
95 1741 1581 1300 1017 754
100 1872 1744 1574 1251 978
105 2020 1910 1737 1518 1234 935
110 2076 1903 1691 1497 1193 858 522
115 2069 1867 1687 1500 1108 717 646
120 2040 1874 1701 1384 1066 868
125 1913 1744 1520 1296 1168
130 1927 1860 1714 1567 1398
135 1772 1596
