External Static Pressure and Air Flow Tables
DUCTED HIGH STATIC
B8 Units
B8 Unit External Static Pressure and Air Flow Table.
Table 23: B8 Unit External Static Pressure and Air Flow Table.
Set Value
Static Pressure (in. wg)
0.23 0.35 0.47 0.59 0.71 0.79 0.86 0.90 0.98
60 1,430 - - - - - - - -
65 1,861 1,388 - - - - - - -
70 2,249 1,663 - - - - - - -
75 2,511 2,009 1,578 - - - - - -
80 2,694 2,461 1,949 - - - - - -
85 2,941 2,775 2,380 1,974 1,123 - - - -
91 3,167 3,076 2,786 2,387 1,914 - - - -
95 3,298 3,227 3,040 2,719 2,345 1,787 1,059 - -
100 3,298 3,227 3,118 2,998 2,680 2,454 2,147 1,522 -
105 3,291 3,224 3,118 2,998 2,864 2,733 2,443 2,398 1,811
1. All static pressure air flow rates are listed in CFM.
2. The tables above show the correlation between air flow rates and external static pressure.
3. The tables above show the available external static pressure range.
If the external static pressure of the installed indoor unit is less than the lowest value (as mentioned in the table), the indoor unit components can fail.
