Copyright ©2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
- 28 -
Explodede View
6. Exploded View
649950
268711B
268711C
W6640
268711A
W6200
261704
268711D
Control Box
n U7 chassis, ARUN100LSS0/ARUN120LSS0/ARUV140LSS0
SVC Location Applied Housing color
263230A Subcool out pipe + liquid pipe yellow
263230B Suction pipe + hex + discharge pipe purple
263230C Air temperature sensor green
