Multi V S Outdoor Unit
2. Select the Best Location
4
Installation of Outdoor Units
Seasonal wind and cautions in winter
• Sufficient measures are required in a snow area or severe cold area in winter so that product can be operated
well.
• Get ready for seasonal wind or snow in winter even in other areas.
• Install a suction and discharge duct not to let in snow or rain.
• Install the outdoor unit not to come in contact with snow directly. If snow piles up and freezes on the air suction
hole, the system may malfunction. If it is installed at snowy area, attach the hood to the system.
• The raised support platform must be high enough to allow the unit to remain above possible snow drifts, andmust
be higher than the maximum anticipated snowfall for the location
1. Don't install the suction hole and discharge hole of the Outdoor unit facing the seasonal wind.
