2. Specifications
7
MULTI V S Outdoor Unit
Product Data
HP 10 12
Model Name ARUN100LSS0 ARUN120LSS0
Capacity
Cooling
kW 28.0 33.6
kcal/h 24,100 28,900
Btu/h 95,900 114,700
Heating
kW 30.6 36.7
kcal/h 26,300 31,600
Btu/h 104,400 125,200
Input (Rated)
Cooling kW 12.44 15.27
Heating kW 8.50 12.23
EER 2.25 2.20
SEER 6.28 6.50
COP 3.60 3.00
SCOP 4.21 4.32
Power Factor Rated - 0.93 0.93
Exterior
Color Warm Gray Warm Gray
RAL (Classis) RAL 7044 RAL 7044
Heat Exchanger Wide Louver Plus Wide Louver Plus
Compressor
Type Hermetically Sealed Scroll Hermetically Sealed Scroll
Piston Displacement
cm
3
/rev
62.1 62.1
Number of Revolution rev/min 3,600 3,600
Motor Output W 5,300 5,300
Starting Method Inverter Inverter
Oil Type FW68D(PVE) FW68D(PVE)
Oil Charge 2,600 3,400
Fan
Type Propeller fan Propeller fan
Motor Output x Number W 250 x 2 250 x 2
Air Flow Rate(High)
m³/min 190 190
ft³/min 6,710 6,710
Drive DC INVERTER DC INVERTER
Discharge Side / Top Side Side
Pipe Connections
Liquid mm(inch) Ø 9.52(3/8) Ø 12.7(1/2)
Gas mm(inch) Ø 22.2(7/8) Ø 28.58(1 1/8)
Dimensions(W x H x D)
mm 1,090 × 1,625 × 380 1,090 x 1,625 x 380
inch 42-29/32 × 63-31/32 × 14-31/32 42-29/32 × 63-31/32 × 14-31/32
Net Weight
kg 142 155
lbs 312 340
Sound Pressure
Level
Cooling dB(A) 58 60
Heating dB(A) 58 60
Sound Power
Level
Cooling dB(A) 77 78
Heating dB(A) 79 82
Protection
Devices
High pressure protection - High pressure sensor High pressure sensor
Comperssor/ Fan -
Over-heat protection /
Fan driver overload protector
Over-heat protection /
Fan driver overload protector
Inverter -
Over-heat protection /
Over-current protection
Over-heat protection /
Over-current protection
Communication Cable (VCTF-SB) No. x mm² 2C x 1.0 ~ 1.5 2C x 1.0 ~ 1.5
Refrigerant
Refrigerant name R410A R410A
Precharged Amount
kg 4.5 6.0
lbs 9.9 13.2
t-CO2eq. 9.394 12.525
Control Electronic Expansion Valve Electronic Expansion Valve
Power Supply V, Ø, Hz 380 - 400 - 415, 3, 50/60 380 - 400 - 415, 3, 50/60
Running Current
Cooling A 20.32 - 19.31 - 18.61 24.95 - 23.7 - 22.84
Heating A 13.89 - 13.19 - 12.72 19.98 - 18.98 - 18.30
Number of maxmum connectable indoor units 16 20
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound pressure level is measured on the rated condition in the anechoic rooms by ISO 3745 standard.
Sound power level is measured on the rated condition in the semi-anechoic rooms by ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
4. Performances are based on the following conditions :
• *Cooling : Indoor Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• *Heating : Indoor Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe Length is 7.5m and difference of Elevation (Outdoor ~ Indoor Unit) is 0m.
5. EUROVENT Test Condition :
• Performance values in this PDB are based on Ceiling mounted cassette combination.
• Refer to EUROVENT web site(www.eurovent-certification.com) for other indoor unit combination and more detail test conditions.
6. The maximum combination ratio is 160%.
7. This product contains Fluorinated greenhouse gases.
9. * : In case of ARUN050GSL0, maximum combination ratio is 130%.
