LG ARUN050GSS0 User Manual

Multi V S Outdoor Unit
7. Refrigerant Piping System
16
Installation of Outdoor Units
■ Limits of pipe length and difference in height
 Standard Model (ARUN****SS0)
 Compact Model (ARUN****SL0)
Note
• * : Assume equivalent piping length of Y branch to be 0.5m, that of header to be 1m, calculation purpose.
• ** : To apply Conditional Application
WARNING
When the below condition is satisfied, the diameter of main pipe (A) must be increased accordingto below
table.
• The equivalent length between outdoor unit and the farthest indoor unit is 90m or more
(Liquid and Gas pipes are increased)
* Compact models are not applied.
Connection method Y branch only
Combination of
Y branch / header
Header only
Max. pipe length
Longest pipe length (L)
: between Outdoor Unit ↔ Indoor Unit
A+B+C+D+e ≤
150m(200m**)
A+B+b ≤ 150m(200m**)
A+C+e ≤ 150m(200m**)
A+f ≤ 150 m
Longest pipe equivalent length* (L)
: between Outdoor Unit ↔ Indoor Unit
175m(225m**) 175m(225m**) 175m
Longest pipe length after 1st branch (ℓ)
40m (90 m**) 40m (90 m**) 40m
Total pipe length 300 m 300m 300m
Max. difference
in height
Difference in height (H)
: between Outdoor Unit ↔ Indoor Unit
50m 50m 50m
Difference in height (h)
: between Indoor Unit ↔ Indoor Unit
15m 15m 15m
Connection method Y branch only
Combination of
Y branch / header
Header only
Max. pipe length
Longest pipe length (L)
: between Outdoor Unit ↔ Indoor Unit
A+B+C+D+e ≤ 80m
A+B+b ≤ 80 m
A+C+e ≤ 80 m
A+f ≤ 80 m
Longest pipe equivalent length* (L)
: between Outdoor Unit ↔ Indoor Unit
100 m 100 m 100 m
Longest pipe length after 1st branch (ℓ)
40 m 40 m 40 m
Total pipe length 150 m 150 m 150 m
Max. difference
in height
Difference in height (H)
: between Outdoor Unit ↔ Indoor Unit
30 m 30 m 30 m
Difference in height (h)
: between Indoor Unit ↔ Indoor Unit
15 m 15 m 15 m
