LG ARUN050GSS0 User Manual

MULTI V S Outdoor Unit
4. Electric Characteristics
14
Product Data
4.1 1 Phase / Heat Pump
■ 50Hz
■ 60Hz
Model
Unit Power Supply COMP OFM
Hz Volts Voltage-range MCA TOCA MFA MSC RLA(Cooling) RLA(Heating) kW FLA
4 HP 50 220-240 Min.:198, Max.:264 25.0 26.0 30 - 17.8 13.5 0.12 1.0
5 HP
(1Fan)
50 220-240 Min.:198, Max.:264 27.5 26.0 30 - 24.0 17.6 0.12 1.0
5 HP
(2Fan)
50 220-240 Min.:198, Max.:264 27.5 26.0 30 - 20.5 18.5 0.35 1.0
6 HP 50 220-240 Min.:198, Max.:264 29.4 26.0 40 - 23.2 22.4 0.35 1.0
Model
Unit Power Supply COMP OFM
Hz Volts Voltage-range MCA TOCA MFA MSC RLA(Cooling) RLA(Heating) kW FLA
4 HP 60 220 Min.:198, Max.:242 25.0 26.0 30 - 17.8 13.5 0.12 1.0
5 HP
(1Fan)
60 220 Min.:198, Max.:242 27.5 26.0 30 - 24.0 17.6 0.12 1.0
5 HP
(2Fan)
60 220 Min.:198, Max.:242 27.5 26.0 30 - 20.5 18.5 0.35 1.0
6 HP 60 220 Min.:198, Max.:242 29.4 26.0 40 - 23.2 22.4 0.35 1.0
Note
1. Voltage supplied to the unit terminals should be within the minimum and maximum
range.
2. Maximum allowable voltage unbalance between phase is 2%.
3. MSC means the Max. current during the starting of compressor.
4. MSC and RLA are measured as the compressor only test condition.
5. OFM are measured as the outdoor unit test condition.
6. TOCA means the total over current value of each outdoor unit.
7. Select the wire size based on the larger value among MCA or TOCA.
8. MFA is recommended fuse amps.
9. TOCA is minimum required amperes for selecting the circuit breaker and ground fault
circuit interrupter. Please select the circuit breaker size equal or greater than TOCA.
All installation site must require attachment of an earth leakage breaker.[Circuit
breaker type is ELCB (Earth Leakage Circuit Breaker)].
10.Select the electrical equipment of combination unit according to the electrical
characteristics of individual unit.
Symbols
MCA : Minimum Circuit Amperes (A)
TOCA : Total Over Current Amperes (A)
MFA : Maximum Fuse Amperes (A)
MSC : Maximum Starting Current (A)
RLA : Rated Load Amperes (A)
OFM : Outdoor Fan Motor
kW : Fan Motor rated output (kW)
FLA : Full Load Amperes (A)

LG ARUN050GSS0 Specifications

General

Brand	LG
Model	ARUN050GSS0
Category	Air Conditioner
Language	English
