MULTI V S Outdoor Unit
6. Capacity Tables
46
Product Data
Note
1. TC: Total Capacity(kW), PI : Power Input(kW, Comp. + Outdoor fan motor)
2. Capacity tables show the average value of conditions which may occur.
50
10 11.3 1.92 13.6 2.22 15.7 2.53 16.8 2.71 17.9 2.87 20.0 3.23 22.3 3.60
12 11.3 1.94 13.6 2.24 15.7 2.57 16.8 2.75 17.9 2.93 20.0 3.29 22.3 3.66
14 11.3 1.96 13.6 2.28 15.7 2.61 16.8 2.79 17.9 2.97 20.0 3.33 22.3 3.72
16 11.3 2.00 13.6 2.32 15.7 2.65 16.8 2.85 17.9 3.01 20.0 3.39 22.3 3.78
18 11.3 2.02 13.6 2.34 15.7 2.69 16.8 2.89 17.9 3.07 20.0 3.46 22.3 3.86
20 11.3 2.04 13.6 2.38 15.7 2.75 16.8 2.93 17.9 3.13 20.0 3.52 22.3 3.94
21 11.3 2.06 13.6 2.40 15.7 2.77 16.8 2.97 17.9 3.15 20.0 3.56 22.3 3.98
23 11.3 2.10 13.6 2.44 15.7 2.81 16.8 3.01 17.9 3.21 20.0 3.62 22.3 4.06
25 11.3 2.12 13.6 2.49 15.7 2.87 16.8 3.07 17.9 3.31 20.0 3.80 22.3 4.34
27 11.3 2.16 13.6 2.57 15.7 3.03 16.8 3.27 17.9 3.52 20.0 4.06 22.3 4.63
29 11.3 2.28 13.6 2.73 15.7 3.21 16.8 3.48 17.9 3.74 20.0 4.30 22.3 4.91
31 11.3 2.40 13.6 2.89 15.7 3.41 16.8 3.68 17.9 3.98 20.0 4.59 22.3 5.23
33 11.3 2.55 13.6 3.05 15.7 3.62 16.8 3.90 17.9 4.22 20.0 4.87 22.3 5.58
35 11.3 2.69 13.6 3.23 15.7 3.82 16.8 4.14 17.9 4.47 20.0 5.15 22.3 5.92
37 11.3 2.85 13.6 3.41 15.7 4.04 16.8 4.38 17.9 4.73 20.0 5.50 22.3 6.28
39 11.3 2.98 13.6 3.59 15.7 4.29 16.8 4.63 17.9 4.97 20.0 5.80 22.3 6.65
Combination
(%)
Outdoor
Air Temp.
(℃ DB)
Indoor Air Temp. (DB/WB, °C)
20 23 26 27 28 30 32
14 16 18 19 20 22 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
To Next Page
