MULTI V S Outdoor Unit
6. Capacity Tables
52
Product Data
Note
1. TC: Total Capacity(kW), PI : Power Input(kW, Comp. + Outdoor fan motor)
2. Capacity tables show the average value of conditions which may occur.
70
-19.8 -20 11.5 5.51 11.1 5.53 10.5 5.33 10.1 5.06 9.8 4.81 9.1 4.56
-18.8 -19 11.8 5.53 11.1 5.43 10.5 5.23 10.1 4.96 9.8 4.72 9.1 4.47
-16.7 -17 11.8 5.31 11.1 5.21 10.5 5.02 10.1 4.76 9.8 4.53 9.1 4.30
-13.7 -15 11.8 5.00 11.1 4.89 10.5 4.72 10.1 4.48 9.8 4.27 9.1 4.04
-11.8 -13 11.8 4.80 11.1 4.69 10.5 4.53 10.1 4.30 9.8 4.10 9.1 3.88
-9.8 -11 11.8 4.59 11.1 4.48 10.5 4.32 10.1 4.11 9.8 3.92 9.1 3.71
-9.5 -10 11.8 4.56 11.1 4.45 10.5 4.29 10.1 4.08 9.8 3.89 9.1 3.69
-8.5 -9.1 11.8 4.46 11.1 4.35 10.5 4.19 10.1 3.98 9.8 3.81 9.1 3.60
-7 -7.6 11.8 4.30 11.1 4.19 10.5 4.04 10.1 3.84 9.8 3.67 9.1 3.48
-5 -5.6 11.8 4.09 11.1 3.98 10.5 3.84 10.1 3.65 9.8 3.50 9.1 3.31
-3 -3.7 11.8 3.88 11.1 3.77 10.5 3.64 10.1 3.46 9.8 3.32 9.1 3.14
0 -0.7 11.8 3.57 11.1 3.46 10.5 3.34 10.1 3.18 9.8 3.05 9.1 2.88
3 2.2 11.8 3.25 11.1 3.14 10.5 3.03 10.1 2.89 9.8 2.79 9.1 2.63
5 4.1 11.8 3.04 11.1 2.93 10.5 2.83 10.1 2.70 9.8 2.61 9.1 2.46
7 6 11.8 2.83 11.1 2.72 10.5 2.63 10.1 2.51 9.8 2.43 9.1 2.29
9 7.9 11.8 2.56 11.1 2.46 10.5 2.37 10.1 2.27 9.8 2.20 9.1 2.07
11 9.8 11.8 2.38 11.1 2.29 10.5 2.21 10.1 2.11 9.8 2.05 9.1 1.92
13 11.8 11.8 2.23 11.1 2.14 10.5 2.07 10.1 1.97 9.8 1.92 9.1 1.80
15 13.7 11.8 2.10 11.1 2.02 10.5 1.95 10.1 1.86 9.8 1.81 9.1 1.70
60
-19.8 -20 10.1 5.45 9.6 5.24 9.0 4.95 8.7 4.68 8.4 4.43 7.8 4.18
-18.8 -19 10.1 5.34 9.6 5.13 9.0 4.85 8.7 4.59 8.4 4.34 7.8 4.10
-16.7 -17 10.1 5.11 9.6 4.90 9.0 4.64 8.7 4.39 8.4 4.16 7.8 3.92
-13.7 -15 10.1 4.78 9.6 4.58 9.0 4.33 8.7 4.11 8.4 3.89 7.8 3.67
-11.8 -13 10.1 4.58 9.6 4.38 9.0 4.14 8.7 3.93 8.4 3.72 7.8 3.51
-9.8 -11 10.1 4.36 9.6 4.16 9.0 3.94 8.7 3.74 8.4 3.55 7.8 3.34
-9.5 -10 10.1 4.32 9.6 4.13 9.0 3.91 8.7 3.71 8.4 3.52 7.8 3.31
-8.5 -9.1 10.1 4.21 9.6 4.02 9.0 3.81 8.7 3.62 8.4 3.43 7.8 3.23
-7 -7.6 10.1 4.05 9.6 3.86 9.0 3.66 8.7 3.48 8.4 3.30 7.8 3.10
-5 -5.6 10.1 3.83 9.6 3.65 9.0 3.46 8.7 3.29 8.4 3.13 7.8 2.94
-3 -3.7 10.1 3.61 9.6 3.43 9.0 3.25 8.7 3.10 8.4 2.95 7.8 2.77
0 -0.7 10.1 3.28 9.6 3.11 9.0 2.95 8.7 2.82 8.4 2.69 7.8 2.51
3 2.2 10.1 2.95 9.6 2.79 9.0 2.65 8.7 2.53 8.4 2.42 7.8 2.26
5 4.1 10.1 2.73 9.6 2.57 9.0 2.45 8.7 2.35 8.4 2.25 7.8 2.09
7 6 10.1 2.51 9.6 2.36 9.0 2.25 8.7 2.16 8.4 2.07 7.8 1.92
9 7.9 10.1 2.24 9.6 2.10 9.0 2.00 8.7 1.93 8.4 1.85 7.8 1.72
11 9.8 10.1 2.09 9.6 1.96 9.0 1.87 8.7 1.80 8.4 1.72 7.8 1.60
13 11.8 10.1 1.96 9.6 1.84 9.0 1.75 8.7 1.68 8.4 1.62 7.8 1.50
15 13.7 10.1 1.85 9.6 1.74 9.0 1.66 8.7 1.59 8.4 1.53 7.8 1.42
50
-19.8 -20 8.4 4.52 7.9 4.26 7.5 4.03 7.2 3.81 7.0 3.60 6.5 3.40
-18.8 -19 8.4 4.43 7.9 4.17 7.5 3.95 7.2 3.73 7.0 3.53 6.5 3.34
-16.7 -17 8.4 4.23 7.9 3.99 7.5 3.77 7.2 3.57 7.0 3.38 6.5 3.19
-13.7 -15 8.4 3.95 7.9 3.73 7.5 3.53 7.2 3.34 7.0 3.17 6.5 2.99
-11.8 -13 8.4 3.78 7.9 3.56 7.5 3.37 7.2 3.19 7.0 3.03 6.5 2.86
-9.8 -11 8.4 3.59 7.9 3.38 7.5 3.21 7.2 3.03 7.0 2.89 6.5 2.72
-9.5 -10 8.4 3.56 7.9 3.35 7.5 3.18 7.2 3.01 7.0 2.87 6.5 2.70
-8.5 -9.1 8.4 3.47 7.9 3.27 7.5 3.10 7.2 2.93 7.0 2.79 6.5 2.63
-7 -7.6 8.4 3.33 7.9 3.13 7.5 2.98 7.2 2.82 7.0 2.69 6.5 2.53
-5 -5.6 8.4 3.14 7.9 2.96 7.5 2.81 7.2 2.66 7.0 2.54 6.5 2.39
-3 -3.7 8.4 2.96 7.9 2.78 7.5 2.65 7.2 2.51 7.0 2.40 6.5 2.26
0 -0.7 8.4 2.68 7.9 2.52 7.5 2.40 7.2 2.28 7.0 2.19 6.5 2.05
3 2.2 8.4 2.40 7.9 2.25 7.5 2.16 7.2 2.05 7.0 1.97 6.5 1.84
5 4.1 8.4 2.21 7.9 2.08 7.5 1.99 7.2 1.89 7.0 1.83 6.5 1.71
7 6 8.4 2.03 7.9 1.90 7.5 1.83 7.2 1.74 7.0 1.68 6.5 1.57
9 7.9 8.4 1.83 7.9 1.71 7.5 1.65 7.2 1.57 7.0 1.52 6.5 1.42
11 9.8 8.4 1.71 7.9 1.60 7.5 1.55 7.2 1.47 7.0 1.42 6.5 1.33
13 11.8 8.4 1.61 7.9 1.51 7.5 1.45 7.2 1.38 7.0 1.34 6.5 1.25
15 13.7 8.4 1.52 7.9 1.43 7.5 1.37 7.2 1.30 7.0 1.26 6.5 1.18
Combination
(%)
Outdoor air temp
Indoor air temp. ℃ DB
16 18 20 21 22 24
℃ DB ℃ WB
TC PI TC PI TC PI TC PI TC PI TC PI
