CAUTION
• Ratio of the connectable Indoor Units to the Outdoor: Within 50
~ 130%
• Ratio of running Indoor Units to the Outdoor: Within 10 ~ 100%
• A combination operation over 100% cause to reduce each in-
door unit capacity.
!
CAUTION
• The wall thickness of the piping should comply with the relevant
local and national regulations for the designed pressure 3.8MPa
• Since R410A is a mixed refrigerant, the required additional re-
frigerant must be charged in its liquid state.
• If the refrigerant is charged in its gaseous state, its composition
changes and the system will not work properly.
• Do not place the refrigerant container under the direct rays of
the sun to prevent it from exploding.
• For high-pressure refrigerant, any unapproved pipe must not be
used.
• Do not heat pipes more than necessary to prevent them from
softening.
• Be careful not to install wrongly to minimize economic loss be-
cause it is expensive in comparison with R22.
!
Chassis U3 U4
External
Apperance
Outdoor Fan 2 FAN 1 FAN
Phase 1Ø 3Ø 1Ø
PFC PFC PFC Active Filter PFC
Model
Heat
Pump
ARUN50GS2A
ARUN60GS2A
ARUN40LS2A
ARUV50LS2A
ARUN60LS2A
ARUN40LS2B
ARUN50LS2B
ARUN60LS2B
ARUN40GS2A
Cooling
Only
ARUV60GS2A
ARUV40LS2A
ARUV50LS2A
ARUV60LS2A
ARUV40LS2B
ARUV50LS2B
ARUV60LS2B
ARUV50GS2A
ARUV40GS2A
Power Supply : 1Ø, 220~240V, 50Hz / 1Ø, 220V, 60Hz
Connectable Indoor Unit
Heat Pump Model
Chassis
System(HP)
Model
Refrigerant
Product charge kg
CF(Correction Factor)
kg
Max. Connectable No. of Indoor Units
Net Weight(Gross Weight) kg
Dimensions(WxHxD)
mm
inch
Connecting
Pipes
Liquid Pipes
mm
inch
Gas Pipes
mm
inch
Connection Type
U4 U3 U3
456
ARUN40GS2A ARUN50GS2A ARUN60GS2A
1.8 3.0 3.0
000
689
77 106 106
950×834×330 950×1380×330 950×1380×330
37.4×32.8×13.0 37.4×54.3×13.0 37.4×54.3×13.0
9.52 9.52 9.52
3/8 3/8 3/8
15.88 15.88 19.05
5/8 5/8 3/4
FLARE BRAZING BRAZING
Power Supply : 3Ø, 380~415V, 50Hz/ 3Ø, 380V, 60Hz
*A:PFC model, B:Active Filter model
Chassis
System(HP)
Model
Refrigerant
Product charge kg
CF(Correction Factor)
kg
Max. Connectable No. of Indoor Units
Net Weight(Gross Weight) kg
Dimensions(WxHxD)
mm
inch
Connecting
Pipes
Liquid Pipes
mm
inch
Gas Pipes
mm
inch
Connection Type
U3 U3 U3
456
ARUN40LS2* ARUN50LS2* ARUN60LS2*
ARUV40LS2* ARUV50LS2* ARUV60LS2*
3.0 3.0 3.0
-0.5 0 0
689
107 107 107
950 x 1,380 x 330 950 x 1,380 x 330 950 x 1,380 x 330
37.4 x 54.3 x 13.0 37.4 x 54.3 x 13.0 37.4 x 54.3 x 13.0
Ø9.52 Ø9.52 Ø9.52
3/8 3/8 3/8
Ø15.88 Ø15.88 Ø19.05
5/8 5/8 3/4
Cooling Only Model
Chassis
System(HP)
Model
Refrigerant
Product charge kg
CF(Correction Factor)
kg
Max. Connectable No. of Indoor Units
Net Weight(Gross Weight) kg
Dimensions(WxHxD)
mm
inch
Connecting
Pipes
Liquid Pipes
mm
inch
Gas Pipes
mm
inch
Connection Type
U4 U4 U3
456
ARUV40GS2A ARUV50GS2A ARUN60GS2A
1.95 1.95 3.0
000
689
78 78 106
950×834×330 950×834×330 950×1380×330
37.4×32.8×13.0 37.4×32.8×13.0 37.4×54.3×13.0
9.52 9.52 9.52
3/8 3/8 3/8
15.88 15.88 19.05
5/8 5/8 3/4
FLARE FLARE BRAZING
should be connected with "2 series" indoor unit only.
Ex) ARNU07GSEA2
BEFORE INSTALLATION
Environment-friendly Alternative Refrigerant
R410A
The refrigerant R410A has the property of higher operating pressure in
comparison with R22.
Therefore, all materials have the characteristics of higher resisting
pressure than R22 ones and this characteristic should be also consid-
ered during the installation.
R410A is an azeotrope of R32 and R125 mixed at 50:50, so the ozone
depletion potential (ODP) of R410A is 0. These days the developed
countries have approved it as the environment-friendly refrigerant and
encouraged to use it widely to prevent environment pollution.
