LG AS-H1264DM0 - 9 k Btu Airflow and Temp Data

82 2005 Product Data
11. Air Velocity and Temperature Distributions(Reference Data)
General Wall Mouted 7k Btu.
Air velocity [m/s]
2.7m
2m
1m
0m
0m
1m2m3m4m5m
Temperature [˚C]
2.7m
2m
1m
0m
0m
1m2m3m4m5m
0.75
1.0
0.5
25
24
23
Air velocity [m/s]
2.7m
2m
1m
0m
0m
1m2m3m4m5m
Temperature [˚C]
2.7m
2m
1m
0m
0m
1m2m3m4m5m
0.75
1.0
0.5
28
29
30
Cooling
Discharge angle:45°
Heating
Discharge angle:50°
General Wall Mouted 9k Btu.
Air velocity [m/s]
2.7m
2m
1m
0m
0m1m2m3m4m5m
Temperature [˚C]
2.7m
2m
1m
0m
0m1m2m3m4m5m
0.75
1.0
0.5
25
24
23
Air velocity [m/s]
2.7m
2m
1m
0m
0m1m2m3m4m5m
Temperature [˚C]
2.7m
2m
1m
0m
0m1m2m3m4m5m
0.75
1.0
1.2
0.5
28
29
30
Cooling
Discharge angle:45°
Heating
Discharge angle:50°
