LG CB777F-AA - Disassembly

DISASSEMBLY
- 8 -
1. TILT/SWIVEL & BACK COVER REMOVAL
1) Set the monitor face downward.
2) Pressing the latch (a), carefully remove the Tilt/Swivel by pulling it upward.
3) Pressing the latch (b), Back cover by pushing it upward.
4) Release the latch (c).
5) Slide the Back Cover away from the Front Cabinet of the monitor.
(a)
Back Cover
Cabinet
(b)
(c)
1
2
2
3
3
Tip
C
B
A
Tip Spec.
A(Width) : 5.0~15.0mm
B(Depth) : 0.6~0.9mm
C(Height) : 10.0mm
