10 INSTALLATION
Unpacking the Cooktop
1 Unpack and visually inspect the cooktop for
any damage or missing components.
2 Be sure the bottle of cleaner and conditioner
packed in the literature bag is left where the
user can find it easily. It is important that the
ceramic-glass cooktop be pretreated before
use. See Care and Cleaning.
Model and Serial Number Location
The model and serial numbers are located on a
plate on the front side of the cooktop. Please
record them in this guide; you will need them for
warranty registration.
Technical Specifications
30" Technical Specifications
Models CBIH3013BE
Description Induction Cooktop
Electrical
Specifications
Connection
voltage
240/208 VAC 60 Hz., 29.6 A / 27.9 A
Maximum
connected power
load
7100 W / 5806 W
Cooktop Dimensions
30 11/16" (781 mm) (W) × 3 11/16" (94 mm) (H) × 21 1/16" (534
mm) (D)
Countertop Cutout Dimensions
Standard Installation
28 1/2" (724 mm) (W) × 5 3/4" (146 mm) (H) × 19 5/8" (498 mm) (D)
Cooking Zones
Position Size
Power (Level 9 /
Boost)
Front Left 7 3/16" (185 mm)
1717/2617 W (208
V)
2100/3200 W (240
V)
Front Right 6 1/2" (165 mm)
1063/1472 W (208
V)
1300/1800 W (240
V)
Rear Left 6 1/2" (165 mm)
1063/1472 W (208
V)
1300/1800 W (240
V)
Center 9 15/16" (253 mm)
1963/3517 W (208
V)
2400/4300 W (240
V)
