LG CJ65 - Disassembly Instructions

2-9
DISASSEMBLY INSTRUCTIONS
Figure 1
Figure 2
1. Case Top
1-1) Remove the 5 Screws.
1-2) Remove the Case Top.
2. Bracket
2-1) Remove the two Brackets between Front & Back Panel.
You can easily remove the Bracket after the hook detach from Front Panel.
