SPECIFICATIONS
1-14
• GENERAL
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Networked standby : 0.5 W
(If all network ports are activated.)
Dimensions (W x H x D) Approx. 350 mm x 163 mm x 251 mm
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
• INPUTS
Analog audio in (AUX IN) 1.0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R)
Portable in (PORT.IN) 500 mVrms (3.5 mm stereo jack) x 1
Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1
• TUNER
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
AM Tuning Range 522 to 1,620 kHz, 520 to 1,710 kHz or 522 to 1,710 kHz
• SYSTEM
Frequency Response 100 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 75 dB
Bus Power Supply (USB) 5 V 500 mA
• AMPLIFIER (RMS Output power)
Total 720 W RMS
Front 240 W RMS X 2 (3 Ω at 1 kHz, 20 % THD)
Subwoofer 240 W RMS (3 Ω at 60 Hz, 20 % THD)
• FRONT SPEAKER
Type 2 Way 2 Speaker
Impedance 3 Ω
Rated Input Power 240 W RMS
Max. Input power 480 W RMS
Net Dimensions (W x H x D) Approx. 266 mm x 314 mm x 234 mm
• SUBWOOFER SPEAKER
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 240 W RMS
Max. Input power 480 W RMS
Net Dimensions (W x H x D) Approx. 266 mm x 314 mm x 300 mm
• Design and specifications are subject to change without notice.
