5 Appendix
Appendix 41
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D) Approx. 350 mm x 166 mm x 276 mm
Operating temperature 5 °C to 35 °C
Operating humidity 60 %
Inputs
Analog audio in (AUX IN) 2.0 Vrms (1 kHz, 0 dB), 75
Ω
, RCA jack (L, R)
Portable in (PORTABLE IN) 1.0 Vrms (3.5 mm stereo jack) x 1
Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 40 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 75 dB
Bus Power Supply (USB) 5 V
0
500 mA
Amplier (RMS Output power)
Total output 1,100 W RMS
Front 350 W RMS X 2 (4
Ω
at 1 kHz, 25 % THD)
Subwoofer 400 W RMS (3
Ω
at 60 Hz, 25 % THD)
y
Design and specications are subject to change without notice.
