Appendix 61
Appendix
6
Specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) Approx. 350.0 mm x 163.0 mm x 251.0 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 % RH
Inputs/ Outputs
Analog audio in (AUX IN 2) 2.7 Vrms (1 kHz), 75
Ω
RCA jack (L,R)
Portable in (AUX IN 1) 1.3 Vrms (3.5 mm stereo jack) x 1
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector ) x 1
Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 70 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 75 dB
Bus Power Supply (USB) 5 V
0
500 mA
Amplier (RMS Output power)
Total output 950 W RMS
Front 475 W RMS X 2 (3
Ω
at 1 kHz, 25 % THD)
y
Design and specications are subject to change without notice.
