LG CM24 N14 User Manual

MULTI/SINGLE Indoor unit
6. External Static Pressure & Air Flow
19
Ceiling concealed duct - Middle static pressure
 Table 1
Model Step CMM
Static Pressure[mmAq(Pa)]
2(20) 2.5(25) 3(29) 4(39) 6(59) 8(78) 10(98) 12(118) 13(127) 14(137) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW18GM1A0
[CM18 N14]
LOW 13.0 74 76 79 85 93 103 111 117 120 125 128
MID 14.5 79 81 84 89 97 107 114 121 125 128 131
HIGH 16.5 85 87 90 94 103 110 118 125 128 131 134
ABNW24GM1A0
[CM24 N14]
LOW 14.5 79 81 84 89 97 107 114 121 125 128 131
MID 16.5 85 87 90 94 103 110 118 125 128 131 134
HIGH 18.0 90 92 95 99 108 115 122 129 132 135 138
Model Step CMM
Static Pressure[mmAq(Pa)]
2.5(25) 4(39) 5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW30GM1A0
[UM30 N14]
LOW 18.0 96 102 107 104 114 118 122 125 127 132 134
MID 20.0 102 110 114 110 121 125 127 130 133 135 137
HIGH 22.0 110 117 121 118 127 130 133 136 137 138 140
Model Step CMM
Static Pressure[mmAq(Pa)]
4(39) 5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW36GM2A0
[UM36 N24]
LOW 24.0 88 91 95 100 101 108 113 115 118 118 118
MID 28.0 93 97 101 105 108 115 118 120 124 124 124
HIGH 32.0 101 105 109 112 115 119 123 126 128 128 128
Model Step CMM
Static Pressure[mmAq(Pa)]
5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 14(137) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW42GM2A0
[UM42 N24]
LOW 28.0 100 103 106 110 114 118 121 125 128 133 136
MID 33.0 108 111 114 118 122 125 128 131 134 138 141
HIGH 38.0 117 120 124 127 130 133 135 138 141 144 147
Model Step CMM
Static Pressure[mmAq(Pa)]
4(39) 5(49) 6(59) 7(68) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW48GM3A0
LOW 28 74 76 79 82 89 92 94 96 99 102 107
MID 34 78 82 84 89 94 96 98 101 104 106 112
HIGH 40 83 89 92 94 98 1000 102 105 108 110 116
Model Step CMM
Static Pressure[mmAq(Pa)]
4(39) 5(49) 6(59) 7(68) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
ABNW60GM3A0
LOW 40 82 89 92 94 98 100 102 105 108 110 113
MID 45 90 92 96 98 102 104 106 109 112 114 117
HIGH 50 94 97 1000 104 107 109 112 115 117 119 121
