6. External Static Pressure & Air Flow
21
Ceiling concealed duct - Middle static pressure
 Table 2
 ABNW18GM1A0 [CM18 N14], ABNW24GM1A0 [CM24 N14]
(Unit : CMM)
 ABNW30GM1A0 [CM30 N14]
(Unit : CMM)
 ABNW36GM2A0 [CM36 N24]
(Unit : CMM)
Note
The above table shows the correlation between the air rates and E.S.P.
Setting value
Static Pressure (mmAq(Pa))
2.5(25) 4(39) 6(59) 8(78) 10(98) 12(118) 14(137) 15(147)
700 11.3
750 12.8
800 14.4 11.4
850 15.9 13.2 10.2
900 17.5 15.0 12.0
950 19.0 16.7 13.7 10.7
1000 20.6 18.5 15.5 12.5
1050 22.1 20.3 17.3 14.3 11.1
1100 23.7 22.1 19.0 16.1 13.1 10.0
1150 23.8 20.8 17.9 15.1 12.2
1200 22.6 19.7 17.1 14.3 11.3
1250 21.5 19.1 16.5 13.6 11.9
1300 23.3 21.2 18.7 15.8 14.3
1350 23.2 20.8 18.0 16.7
1400 23.0 20.3 19.1
1450 22.5 21.5
1500 23.8
Setting value
Static Pressure (mmAq(Pa))
2.5(25) 4(39) 6(59) 8(78) 10(98) 12(118) 14(137) 15(147)
850 16.8 14.6
900 18.1 15.9
950 19.4 17.2 15.0
1000 20.7 18.5 16.3 13.9
1050 22.0 19.8 17.7 15.3 13.0
1100 23.3 21.1 19.1 16.8 14.6
1150 24.6 22.4 20.5 18.3 16.3 14.2
1200 25.9 23.7 21.8 19.7 17.9 15.9 13.3
1250 25.1 23.2 21.2 19.6 17.5 15.2 14.6
1300 24.6 22.7 21.2 19.2 17.1 16.3
1350 24.2 22.9 20.9 19.0 18.1
1400 24.5 22.6 20.9 19.9
Setting value
Static Pressure (mmAq(Pa))
4(39) 6(59) 8(78) 10(98) 12(118) 14(137) 15(147)
850 24.9
900 27.6 22.7
950 30.4 25.7 20.7
1000 33.1 28.7 24.0
1050 35.9 31.7 27.3 20.8
1100 38.6 34.7 30.5 24.3 20.6
1150 37.8 33.8 27.9 23.8
1200 37.1 31.4 27.0 22.4 20.5
1250 35.0 30.1 25.7 23.7
1280 37.1 32.0 27.6 25.7
