MULTI/SINGLE Indoor unit
2. Specifications
5
Ceiling concealed duct - Middle static pressure
Model Name
ABNW30GM1A0
[UM30 N14]
ABNW36GM2A0
[UM36 N24]
Power Supply V, Ø, Hz
220-240, 1, 50 220-240, 1, 50
220, 1, 60 220, 1, 60
Power Input W 150 210
Running Current A 0.80 1.30
Dimensions Body
W x H x D mm 900 × 270 × 700 1,250 × 270 × 700
W x H x D inch 35-7/16 x 10-5/8 x 27-9/16 49-7/32 x 10-5/8 x 27-9/16
Net Weight Body kg (lbs) 25.3 (55.8) 36.0 (79.4)
Heat Exchanger
(Row x Column x Fins per inch) x No. - (3 x 13 x 18) x 1 (2 x 13 x 18) x 1
Face Area
m
2
(ft
2
)
0.21 (2.25) 0.30 (3.27)
Fan
Type - Sirocco Fan Sirocco Fan
Air Flow
Rate
High-static
Mode
(Factory
Set)
H / M / L
m
3
/min
22.0 / 20.0 / 18.0 32.0 / 28.0 / 24.0
H / M / L
ft
3
/min
777 / 706 / 635 1,130 / 988 / 847
External Static
Pressure
Pa (mmAq) 58.8 (6) 58.8 (6)
Fan Motor
Type - BLDC BLDC
Output W x No. 136.5 x 1 295 x 1
Sound Pressure Level H / M / L dB(A) 37 / 35 / 34 36 / 34 / 33
Sound Power Level Max. dB(A) 62 60
Piping Connections
Liquid mm(inch) Ø 9.52 (3/8) Ø 9.52 (3/8)
Gas mm(inch) Ø 15.88 (5/8) Ø 15.88 (5/8)
Drain (O.D. / I.D.) mm(inch)
Ø 32.0(1-1/4) /
25.0(31/32)
Ø 32.0(1-1/4) /
25.0(31/32)
Safety Devices
- Fuse Fuse
-- -
Power and Communication Cable (included Earth)
No. x mm
2
(AWG)
4C x 0.75 (18) 4C x 0.75 (18)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national code. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound Level Values are measured at Anechoic chamber. Therefore, these values depend on the ambient conditions and values are normally higher
in actual operation.
4. Capacities are net capacities and based on the following conditions. Refer to the Outdoor Unit Specifications for calculating the real capacity.
• Cooling : Indoot Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• Heating : Indoot Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe is standard length and difference of Elevation (Outdoor ~ Indoor Unit) is Zero.
