LG CM2460DAB Simple Manual

Speaker Connection
Red
Black
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
(R03)
(R03)
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
MICRO HI-FI SYSTEM is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
Additional Information
Specifications
Power Requirements
Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions (W x H x D)
Approx. 230 mm x 126 mm
x 253 mm
Bus Power Supply (USB)
5 V 0 500 mA
Amplier
(Total RMS output power)
100 W
Design and specications are subject to change without
notice.
CM2460-CB.AWEULLZ_SIM_ENG_MFL71379811.indd 3 2019-08-20  10:38:23

LG CM2460DAB Specifications

General

RMS rated power	100 W
Number of speakers	2
Subwoofer included	Yes
Playback modes	Repeat all, Repeat one
Channels quantity	2 channels
Disc types supported	CD
Card reader integrated	No
Audio formats supported	MP3, WAV, WMA
Type	Home audio micro system
Product color	Black
Number of optical discs	1 discs
Coloration	Monochromatic
Power source	AC
Tuner type	Analog & digital
RDS features	PLL
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, DAB+, FM
Preset stations quantity	50
Wi-Fi	-
Volume control	Rotary
Equalizer modes	Bass Blast, Classic, Jazz, Pop, Rock, Standart
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	126 mm
Width	230 mm
Height	260 mm
Weight	5000 g
