Connecting 11
Connecting
2
Connecting the
speakers to the unit
Attaching the speakers to the
unit
To connect the cable to the unit, press each plastic
nger pad to open the connection terminals on the
unit. Insert the wire and release the nger pad.
Connect the black wire to the terminals marked -
(minus) and the other end to the terminals marked
+ (plus).
The speakers contain magnet parts, so color
irregularity may occur on the TV screen or PC
monitor screen. Please use the speakers far
away from either TV screen or PC monitor.
>
Caution
Antenna Connection
Be sure to fully extend the FM wire antenna.
