LG CS18AQ - Horizontal Vane Control; Vertical Louver Control

Operating Instructions
The Horizontal Vane can be adjusted by using the remote controller.
1. Press the ON/OFF BUTTON to start the unit.
2. Press the vertical airflow direction button.
Each time the button is pressed, the air-flow
direction is changed in the direction of the arrow.
The Vertical Louvers can be adjusted by using the remote controller.
1. Press the ON/OFF BUTTON to start the unit.
2. Press the horizontal airflow direction button. Each time the button is pressed, the
airflow direction is changed in the direction of the arrow.
STOP
1 Step 2 Step 3 Step 4 Step 5 Step 6 Step Auto Swing
Horizontal Vane Control
Vertical Louver Control
※ Press the Vertical Airflow Direction button once more during Auto Swing at the direction of airflow you want.
※ Press the Horizontal Airflow Direction button once more during Full Auto Swing at the direction of airflow you want.
1 Step 2 Step 3 Step 4 Step 5 Step Left Auto Swing Right Auto Swing Full Auto Swing
STOP
• Manually moving the Horizontal Vane or Vertical Louvers by hand could damage the mechanism.When the
unit is shut off, the the Horizontal Vane and Vertical Louvers will close the air outlet vent of the product.
NOTE
16 Air Conditioner
