LG DH4530T - Specifications

Appendix40
Appendix
6
Specifications
General
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions (W x H x D) 360 x 60 x 306 mm
Net Weight (Approx.) 2.45 kg
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) DC 5 V
0
500 mA
Inputs/ Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector )
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
PORT. IN 0.5Vrms (3.5 mm stereo jack)
Amplier
Stereo mode 42 W + 42 W (3 Ω at 1kHz)
Surround mode
Front 42 W x 2 (3 Ω at 1kHz)
Center 42 W (3 Ω at 1kHz)
Surround 42 W x 2 (3 Ω at 1kHz)
Subwoofer 120 W (4 Ω at 80Hz)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
