19
INSTALLATION
10
Reversethelowerhingebracketandhinge
assembly.
a. Remove one screw from the lower hinge
bracket (on the right) and lift it out. Remove
two screws from the lower hinge assembly (on
the left) and lift it out.
b. Rotate the lower hinge assembly 180
degrees and install it on the right side using
the two screws removed in step a.
c. Mount the lower hinge bracket on the lower
left with the screw removed in step a.
11
Install the side lock rod.
a. Flip the side lock rod over and insert the
lower end into the left hinge bracket.
b. Lower the rod into the guides on the door
while compressing the spring inside the
recess.
NOTE
Make sure the top of the side lock rod is beside
the top lock rod and the two do not overlap each
other. If they are not aligned properly, the door will
not operate properly.
NOTE
Make sure the spring stays on the side lock rod.
