4. Remove two screws and disassembly latch.
5. Hold on the hinge while remove 2 screws of hinge (to
prevent door dropping).
6. Remove door from cabinet cover.
1. Open the door to reverse.
2. Check screws to remove (Left 4, Right 2).
3. Remove four dummy screws by driver.
Reversing the Door
w
WARNING
• To avoid damage to the dryer or the door, support
the door with a stool or box that fits under the
door, or have an assistant support the weight of
the door.
• Always reverse the door BEFORE stacking the
dryer on top of the washer.
• Avoid dropping the door to avoid damage to the
door or the floor.
THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure
to follow the instructions below can result in damage
to the dryer, property damage or injury to persons.
Hinge
Dummy
Screw
Open Door
Remove
Door
Hinge Screw
Latch Screw
INSTALLATION INSTRUCTIONS
CAUTION
Be sure to support the weight of the door before
removing the hinge screws.
To Next Page
