OPERATION_DLE3500* / DLG3501* / DLE3460* / DLG3461* / DLEX3*00* / DLGX3*01*
Control Panel
Non-Steam Models (DLE3500*, DLG3501*, DLE3460*, DLG3461*)
7 6
1 2 3 4
5
Steam Models (DLEX3700*, DLGX3701*)
7 6
1 2 3 4
8 5
Steam Models (DLEX3900*, DLGX3901*)
7 6
1 2 3 4
8 5
NOTE
• Model numbers can be found on the cabinet inside the door.
