COMPONENT TESTING INFORMATION

Auto reset -31°F (-35°C)

Same shape as outlet thermostat.

4. LED Lamp Schematic: If the lamp is turned on

by connecting is normal.

It is not

measured by

multimeter

because V is

3.2V

Measure resistance of the

following terminal

1) Door open

Terminal: COM - NC (1-3)

Terminal: COM - NO (1-2)

2) Door closed

Terminal: COM - NC (1-3)

Terminal: COM - NO (1-2)
