54 55
WARNING !
When you disassemble the lamp connector,
be sure to disconnect the dryer from its electrical
supply. Protect your hands and arms from sharp
edges when working. To reduce the risk of Injury to
persons adhere to all industry recommended safety
procedures including the use of long sleeved gloves
and safety glasses.
the front bulkhead.
the front bulkhead.
TUB DRUM FRONT
DRUM ASSEMBLY
CHANGING THE DRUM LAMP
FOR LG TECHNICIAN
DRYER EXHAUST CHANGE
1.
Remove screw and exhaust duct.
2.
3.
4.
5.
WARNING !
Before performing this exhaust installation, be sure to
disconnect the dryer from its electrical supply. Protect your
hands and arms from sharp edges when working inside the
cabinet. To reduce the risk of Injury to persons adhere to all
industry recommended safety procedures including the useof
long sleeved gloves and safety glasses.
Note
FOR LG TECHNICIAN
To Next Page
