35
PANEL REAR [ELECTRIC]
PANEL REAR [ELECTRIC]
1. Remove 1 screw.
2. Pull out the cover.
3. Remove 3 screws.
4. Disassemble terminal block and
wire from panel rear.
1. Remove one screw for removing
safety cover.
2. Remove 3 screws remained on
the panel rear.
3. Lift out the panel rear.
