CONTROL PANEL ASSEMBLY
1. Remove the 2 screws from the
control panel.
2. Place a towel over the top cover to
prevent scratch to the surface.
Gently lift each corner of the back
panel, then roll it forward so it rests
on top of the dryer.
3. With a flat blade screwdriver,
press the tabs on the side of the
PWB(PCB) box and gently pry it
open.
4. Disconnect the wiring from the
PWB(PCB) board.
5. Disassemble the control panel
assembly from top cover.
To Next Page
