14 INSTALLATION
• There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer
of vibration from one appliance to another. If there is enough vibration, it could cause appliances to
make noise or come into contact, causing paint damage and further increasing noise.
• No other fuel-burning appliance can be installed in the same closet as a dryer.
Installation Spacing for Cabinet
For cabinet installation with a door, minimum ventilation openings in the top of the cabinet are required.
- Description Dimension/Clearance
A Depth of Ventilation Opening
2 7″ (178 mm)
BBack Clearance
2 5″ (127 mm)
C Depth 29 1/4″ (743 mm)
D Front Clearance
2 1″ (25mm)
E Side Clearance
2 1″ (25 mm)
FWidth 27″ (686 mm)
