Soundbar Quick Guide
Installing and using the Product
a Connect the soundbar to your TV via an optical cable or an
HDMI cable.
HDMI OUT
HDMI IN
(ARC)
HDMI IN
OPTICAL
OUT
OPTICAL
IN
5 V 0 500 mA
TM
HDMI d TV
(eARC / ARC)
TM
a
b
E
b
F
A
B
C
c
c
D
a
A Soundbar
B Remote Control Receiver
C Status LED (ABC)
D Rear Speakers
E Wireless Subwoofer - Install it close to the soundbar.
F External Device - (Blu-ray player, game console, etc.)
