LG DS70TR - Appendix; Specifications

61
Appendix
Specifications
General
Power requirements Refer to the main label.
Power Consumption
Refer to the main label.
Networked standby: 2.0 W
Dimensions (W x H x D) Approx. 950.0 mm x 63.0 mm x 115.0 mm (including the base)
Operation Temperature Range 5 °C - 40 °C
Operation Humidity Range 5 % - 80 % RH
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192
kHz
Available Digital Input Audio format
Dolby Digital, Dobly Digital Plus, Dolby TrueHD, Dolby Atmos,
DTS Digital Surround, DTS-HD HRA, DTS-HD MA, DTS:X, PCM
Input/Output
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI™ IN 19-pin (Type A, HDMI™ connection terminal) × 1
HDMI™ d TV (eARC / ARC)
19-pin (Type A, HDMI™ connection terminal) × 1
4K resolution is supported for 4K sources applied with HDCP
2.3 (supported 4K@120 Hz (YCbCr 4:2:0)).
Amplifier (RMS output)
Total 500 W RMS
Front 30WRMS×4(Impedance:6Ω,THD10%)
Centre 30WRMS(Impedance:6Ω,THD10%)
Top centre (Overhead) 30WRMS(Impedance:6Ω,THD10%)
Rear 50WRMS×2(Impedance:4Ω,THD10%)
Subwoofer 220WRMS(Impedance:3Ω,THD10%)
