LG DSH5 - Specifications

Appendix 33
Appendix
5
Specifications
General
Power consumption
Refer to the main label on the unit.
Networked standby : 0.5 W
(If all network ports are activated.)
AC adapter
y
Model : DA-38A25
y
Manufacturer : Asian Power Devices Inc.
y
Input : 100 - 240 V ~ 50 - 60 Hz 1.2 A
y
Output : 25 V
0
1.52 A
Dimensions (W x H x D) 890 mm X 53 mm X 85 mm Without foot
Net Weight (Approx.) 2.34 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Bus Power Supply 5 V
0
500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Available Digital Input Audio format Dolby Digital, DTS Digital Surround, PCM
Input/Output
OPTICAL IN (Digital audio in) 3 V (p-p), Optical jack x 1
PORTABLE IN (Portable in) 0.5 Vrms (3.5 mm stereo jack) x 1
HDMI IN 19 Pin (Type A, HDMI™ connector) x 1
HDMI OUT 19 Pin (Type A, HDMI™ connector) x 1
Amplier (RMS Output)
Total 300 W
Front 60 W x 2 (4
Ω
at 1 khz, THD 10%)
Subwoofer 180 W (3
Ω
at 80 Hz, THD 10%)
