2 Connecting
Connecting 17
Connecting
2
Organising cables
(Optional)
You can organise the cable with cable ties.
1. Hold the cables together with cable ties as shown
below.
2. Tighten cable ties.
y
After all connections are completed, you can
arrange cables as needed.
y
Cable ties are not provided.
,
Note
Connecting the AC
Adapter
Connect the unit to the power supply with the
supplied AC adapter.
1. Connect the supplied AC power cord to the AC
adapter.
2. Connect the AC adapter cable to DC IN adapter
input.
3. Plug the AC power cord into an AC outlet.
Only use the AC adapter supplied with this
device. Do not use a power supply from another
device or manufacturer. Using any other power
cable or power supply may cause damage to the
device and void your warranty.
>
Caution
