LG DSN6Y - Specifications

Appendix42
Appendix
5
Specifications
General
Power consumption
Refer to the main label on the unit.
Networked standby : 1.0 W
(If all network ports are activated.)
AC adapter
y
Model : DA-50F25
y
Manufacturer : Asian Power Devices Inc.
y
Input : 100 - 240 V ~ 50 - 60 Hz
y
Output : 25 V
0
2 A
Dimensions (W x H x D) Approx. 1060.0 mm X 57.0 mm X 85.0 mm With foot
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V
0
500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Audio, DTS Digital Surround, PCM
Input/Output
OPTICAL IN 3 V (p-p), Optical jack x 1
HDMI IN 19 Pin (Type A, HDMI™ connector) x 1
HDMI OUT 19 Pin (Type A, HDMI™ connector) x 1
Amplier (RMS Output)
Total 420 W RMS
Front 80 W RMS x 2 (4
Ω
at 1 kHz, THD 10 %)
Center 40 W RMS (4
Ω
at 1 kHz, THD 10 %)
Subwoofer 220 W RMS (3
Ω
at 80 Hz, THD 10 %)
