Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause permanent
damage to the unit.
COAXIAL (Digital audio out jack)
Connect to digital (coaxial) audio equipment.
AUDIO OUT (Left/Right)
Connect to an amplifier, receiver or stereo system.
AERIAL
Connect the aerial using this jack.
EURO AV2
Connect to another video recorder.
VIDEO OUT
Connect to a TV with video inputs.
EURO AV1 AUDIO/VIDEO (VHS IN+OUT/DVD OUT)
Connect to your TV set or another video recorder.
RF.OUT
Connect to your TV using this jack.
AC Power Cord
Connect to a power
source.
