Connecting the Display
5
Before setting up the monitor, ensure that the power to the monitor,
the computer system, and other attached devices is turned off.
Connecting the stand
1. Place the monitor with its front facing downward on
a soft cloth.
Check the direction of the Stand Base,
and connect it into the Stand Body.
Stand Base
Stand Body
3. Once assembled take the monitor up carefully and face the front side.
Important
This illustration depicts the general model of connection. Your monitor may differ from the
items shown in the picture.
Do not carry the product upside down holding only the stand base. The product may fall and
get damaged or injure your foot.
Use a coin on the back of the stand
base and turn the screw clockwise to
tighten.
or
2.
