83
■ 1180 Microphone
Ch5. Removing and replacing a part
1. Remove the Connector, than Remove the Microphone.
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. System Door(1030), c. Retainer(1100), d. keyboard(1110), e. Button Sub
Board(1120), f. Display Module(1130), g. Mainboard(1140)
