MAKING
CONNECTIONS
This section on
MAKING CONNECTIONS
mainly
uses diagrams for the EC93** models.
Connect various external devices to the TV and
switch input modes to select an external device. For
more information on external device’s connection,
refer to the manual provided with each device.
Available external devices are: HD receivers, DVD
players, VCRs, audio systems, USB storage devic-
es, PC, gaming devices, and other external devices.
NOTE
The external device connection may differ
from the model.
Connect external devices to the TV
regardless of the order of the TV port.
If you record a TV program on a DVD
recorder or VCR, make sure to connect the
TV signal input cable to the TV through a
DVD recorder or VCR. For more information
of recording, refer to the manual provided
with the connected device.
Refer to the external equipment’s manual for
operating instructions.
If you connect a gaming device to the TV,
use the cable supplied with the gaming
device.
In PC mode, there may be noise associated
with the resolution, vertical pattern, contrast
or brightness. If noise is present, change
the PC output to another resolution, change
the refresh rate to another rate or adjust the
brightness and contrast on the PICTURE
menu until the picture is clear.
In PC mode, some resolution settings may
not work properly depending on the graphics
card.
If Ultra HD content is played via PC, the video
or audio may have disruptions intermittently
depending on your PC’s performance. (Only
EC97**, EC98**)
Antenna Connection
IN
ANTENNA/
CABLE
mA Ma
LNB IN
atellit
Wall Antenna
Socket
(*Not
Provided)
Connect the TV to a wall antenna socket with an RF
cable (75 Ω).
NOTE
Use a signal splitter to use more than 2 TVs.
If the image quality is poor, install a signal
amplifier properly to improve the image
quality.
If the image quality is poor with an antenna
connected, try to realign the antenna in the
correct direction.
An antenna cable and converter are not
provided.
Supported DTV Audio: MPEG, Dolby Digital,
Dolby Digital Plus, HE-AAC
This TV cannot receive UHD (3840 x 2160
pixels) broadcasts directly because the
related standards have not been confirmed.
(Only EC97**, EC98**)
28
