MAKING CONNECTIONS
Component Connection
IN
AV2
( Audio in)
IN
COMPONENT
YPB
AUDIO
AV2
PR
VIDEO
VIDEO
AUDIO
LR
GREEN
GREEN
GREEN
BLUE
BLUE
BLUE
RED
RED
RED
RED
RED
RED
WHITE
WHITE
WHITE
YELLOW
YELLOW
(Use the
composite gender
cable provided.)
GREEN
(Use the
component gender
cable provided.)
DVD / Blu-Ray /
HD Cable Box
(*Not
Provided)
Transmits analogue video and audio
signals from an external device to
the TV. Connect the external device
and the TV with a component gender
cable as shown.
NOTE
y If cables are not installed cor-
rectly, it could cause this image to
display in black and white or with
distorted colours.
38
ENG
ENG
