5
pecification
S
Name : Front loading washing machine
Power supply : 220–240 V~, 50 Hz
Size : 686 mm(W)×756 mm(D)×983 mm(H)
Weight : 91 kg
Wash capacity/Max. Watt : 15 kg(2200 W)
Dry capacity/Max. Watt : 8 kg(2150 W)
Spin speed : 1200 rpm max.
Water consumption : 180ℓ
Permissible water pressure : 0.3-10 kgf/㎠ (30-1000 kPa)
❋ The appearance and specifications may be varied without notice to raise the
units quality.
Accessories
Control Panel
Shipping Bolts
Power Plug
• If the supply cord is damaged,
it must be replaced by the
manufacturer or its authorized
service technician in order to
avoid a hazard.
Drum
Drain Plug Drain Pump Filter
Lower cover cap
Door
Adjustable Feet
Drain Hose
Dispenser
Air Vent for Safety
Cold Water Inlet
Back of Washer
