LG F2721STWV User Manual

11
ENGLISH
Unpacking and Removing Transit
Bolts
1
Lift the washing machine off the foam base.
•
After removing the carton and shipping material,
lift the washing machine off the foam base. Make
sure the tub support comes off with the base
and is not stuck to the bottom of the washing
machine.
•
If you must lay the washing machine down to
remove the carton base, always protect the side
of the washing machine and lay it carefully on
its side. DO NOT lay the washing machine on its
front or back.
Tub Support
(Optional)
Carton base
2
Remove the bolt assemblies.
•
Starting with the bottom two transit bolts, use the
spanner (included) to fully loosen all transit bolts
by turning them counterclockwise. Remove the
bolt assemblies by wiggling them slightly while
pulling them out.
Retainer
Transit
bolt
3
Install the hole caps.
•
Locate the hole caps included in the accessory
pack and install them in the transit bolt holes.
Cap
NOTE
•
Save the bolt assemblies for future use. To
prevent damage to internal components, DO NOT
transport the washing machine without reinstalling
the transit bolts.
•
Failure to remove transit bolts and retainers may
cause severe vibration and noise, which can lead
to permanent damage to the washing machine.
The cord is secured to the back of the washing
machine with a transit bolt to help prevent
operation with transit bolts in place.

LG F2721STWV Specifications

General

Door hinge	Left
Motor type	Beltless
Control type	Rotary, Touch
Loading type	Front-load
Product color	Silver
Built-in display	Yes
Appliance placement	Freestanding
Connected load	2200 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Drum capacity	21 kg
Spin-drying class	-
Maximum spin speed	1000 RPM
Noise level (spin)	51 dB
Noise level (wash)	48 dB
Load balancing system	No
Number of rinse selections	5

Weight and Dimensions

Depth	835 mm
Width	700 mm
Height	990 mm
Weight	100000 g
