SPECIFICATIONS
- 3 -
NOTE : Designs and specifications are subject to change without notice.
Power supply AC230V, 50/60Hz
Power consumption 150W
Mass 12.4kg
External dimensions (W X H X D) 23.5
X 430 X 483mm
Operating conditions Temperature : 5˚C to 35˚C, Operation status: Horizontal
Frequency response (audio) 150Hz to 20kHz
Signal-to-noise ratio (audio) More than 80dB (1kHz, NOP, JIS FILTER)
Harmonic distortion (audio) 0.5% (1kHz, at 12W position) (30 kHz LPF/A Filter)
Surround Mode Front: 30W + 30W (THD 10%)
Center: 30W
Surround*: 30W + 30W (8Ω at 1kHz, THD 10%)
Subwoofer*: 50W (4Ω at 30 Hz, THD 10%)
Inputs AUX, COAXAL., OPTICAL AUDIO
Satellite Speaker (FE-3000TE) Active Subwoofer (FE-3000AWE)
Type 1 Way 1 Speaker 1 Way 1 Speaker
Impedance 8Ω 4Ω
Frequency Response 110~20,000 Hz 40~2,500Hz
Sound Pressure Level 83dB/W(1m) 82dB/W(1m)
Rated Input Power 30W 50W
Max. Input Power 60W 100W
Net Dimensions (
W
X H
X D) 90 X 125 X 107mm 235 X 430 X 483mm
Net Weight 0.7kg 12.4kg
