Appendix 33
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D)
Approx. 615 mm x 272 mm x 318 mm
(Approx. 242.1 inch x 107 inch x 125.1 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Inputs
Analog audio in (AUX IN) 1.2 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R)
Microphone Sensitivity 20 mV (1 kHz), 6.3 mm jack
System
Frequency Response 80 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 1 A
Amplier (RMS Output power)
Total output 220 W RMS (3 Ω at 1 kHz, 10 % THD)
y Design and specications are subject to change without notice.
