- 16 -
4. TROUBLE IN DPM
TROUBLE IN DPM
NO
NO
TROUBLE IN U201
CHECK PC
PC IS NOT GOING
INTO DPM OFF MODE
CHECK H/V SYNC LINE
YES
YES
CHECK
R442, R443
CHECK
U201 PIN 27,28
SYNC PULSE ?
3
3
Waveforms
R216, R778 H-Sync
3
R217, R781 V-Sync
