- 9 -
Power Board
Main Board
LCD Module
Control Board
CN1
J702
J705
J710
CN3
CN2
CN4
CN5
J1
WIRING DIAGRAM
(Hydis Module)
Connector Ass’y P/N:
6631T12002L
Connector Ass’y P/N:
6631T25008V
Connector Ass’y P/N:
6631T11012Q
Connector Ass’y P/N:
6631T12002M
